    PM-H019SRC

    Product features:

    • Industrial-grade 19" SXGA LCD panel with 50k backlight lifetime
    • True-flat touchscreen with multi-touch projected capacitive control
    • IP66 grade aluminum alloy front panel
    • Video Input Interfaces:1 x VGA / 1 x HDMI / 1 x DVI
    • Support USB Interfaces for Touch Function
    • Supports 19 inch Rack mount / VESA 100mm x 100mm mounting holes
    • Wide Operating Temperature -20°C to 70°C
    • 12V to 24V DC Wide Range Power Input
    CERoHSFCIP65
    Visit:1198
    Description Specifications Dimension drawing Order Info Driver download

    Display

    Panel Size

    19" ( 5:4 )

    Resolution

    1280 x 1024

    Display Brightness

    450 cd/m2

    Contrast Ratio

    1000:1

    Backlight Lifetime

    50000 Hr (min.)

    Viewing Angle

    85 / 85 / 80 / 80 (CR≥10) ( L / R / U / D )

    Touch screen

    Touch Type

    10 point PCAP

    Surface Hardness

    ≥7H

    I / O

    VGA

    1 x VGA

    H-DMI

    1 x H-DMI

    DVI

    1 x DVI

    USB

    1 x Touch  USB

    Other I/O Interface

    1 x OSD Control Key

    Power

    Power Adapter

    1 x Optional AC/DC 12V/4A , 48W

    Power Input

    2-pin Terminal Block Connector with Power Input 12~24VDC

    Power Consumption

    ≦30W

    Physical

    Material

    Aluminum alloy panel, anodized treatment

    Mounting

    19.0-inch Rack Mount / Stand / Wall / VESA / Panel

    Dimension (W x H x D)

    482 x 357 x 55 mm

    Height

    7U

    Packing Size

    500 x 180 x 450 mm

    Weight (Net)

    5.2 kg

    Environment

    Operating Temperature

    -20~70°C  ( -4~158°F )

    Storage Temperature

    -30~80°C (-22~176°F)

    Relative Humidity

    5%~95%@40°C, non-condensing

    Vibration Protection

    1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

    IP Level

    Front Panel IP66

    EMC

    CE, FCC,Class A, ROHS, IEC / EN 62368-1

    ORDERING INFORMATION

    AVAILABLE MODELS

    DESCRIPTION

    PM-H019SRC

    19” SXGA LED / Resolution 1280 x 1024 / PCAP Touch / 1 x VGA / 1 x H-DMI / 1 x DVI / 1 x T-USB / DC IN 12~24V



    PACKING LIST

    1 x 19Rack Mount Touch Monitor

    1 x 1.5m H-DMI Cable

    1.5m T-USB Cable

    Embedded Buckles

    1 x Power Adaptor
