System

CPU

Intel® 8th Gen Core i3-8145U 2.1GHz / i5-8265U 1.6GHz / i7-8565U 1.8GHz , TDP 25W

L2 Cache

4MB / 6MB / 8MB

System Chipset

Integrated with Intel® SoC

Memory

DDR4L 2400MHz 4GB, Up to 64GB

Harddisk

1 x M.2 120G SSD / ( 250G / 500G / 2TB SSD) / 1 x 2.5” SATA

Graphics

Intel HD Graphics 620

Network

Intel® I211-AT GbE LAN

Audio

Realtek ACL662 Audio controller

TPM

TPM2.0

Operation System

Windows 10 / 11， Linux, Ubuntu

I / O

VIDEO

1 x DP / 1 x H-DMI

LAN

2 x LAN 10/100/1000/2500 Mbps

USB

1 x USB2.0 / 4 x USB3.0

COM

6 x RS232 ( optional )

Audio

1x Audio_out & Mic_in

Button

RAFI FS22+ Select / Green / Red / Stop Button ( optional )

Bracket kit

Stainless Steel 48 Series

Other I/O Interface

Optional （WiFi / Bluetooth / 4G / )

Display

LCD Size

15.6" ( 16:9 )

Resolution

1920 x 1080  ( FHD )

Brightness (cd/m²)

450

Contrast Ratio

1000:1

Backlight MTBF

50000 hrs

Viewing Angle

89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )

Touch screen

Touch Type

10 point PCAP

Surface Hardness

≥7H

Power

Power Adapter

1 x Optional AC/DC 12V/5A , 60W

Power Input

DC 9V~36V

Power Consumption

≦30W

Physical

Material

Aluminum Alloy Shell

Mounting

Stand / Wall / VESA / Panel

Dimension (W x H x D）

400 x 315 x 130 mm

Packing Size

500 x 180 x 450 mm

Weight (Net)

12.0 KG

Environment

Operating Temperature

-20~70°C  ( -4~158°F )

Storage Temperature

-30~80°C (-22~176°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

Front Panel IP66

EMC

CE, FCC，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

DCP-3156WAC

15.6” TFT LED / Intel Core i3-8145 2.1GHz / PCAP Touch / DP / HDMI / LAN / USB / COM / RAFIFS22+Select / Green / Red /

Stop Button （RAFI FS22 Button Optional ) / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

DCP-5156WAC

15.6” TFT LED / Intel Core i5-8265U 1.6GHz / PCAP Touch / DP / HDMI / LAN / USB / COM / RAFIFS22+Select / Green / Red /

Stop Button / （RAFI FS22 Button Optional ) / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

DCP-7156WAC

15.6” TFT LED / Intel Core i7-8565U 1.8GHz / PCAP Touch / DP / HDMI / LAN / USB / COM / RAFIFS22+Select / Green / Red /

Stop Button / （RAFI FS22 Button Optional ) / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

CONFIGURATION

DESCRIPTION

Memory

RAM：DDR4L 2400MHz SO-DIMM.4GB/64GB

Harddisk

mSATA SSD：120G (250G/500G/2TB SSD) / 1 x 2.5" SATA

WiFi

Wi-Fi Bluetooth Combo Module, with antenna

PACKING LIST

1x 15.6” Device Control Panel

1x CD-ROM

1x Power Adaptor
