    PPC-17SAC-12th

    Product features:

    • Industrial-grade 17" SXGA LCD panel with 50k backlight lifetime
    • True-flat touchscreen with multi-touch projected capacitive control
    • IP66 grade aluminum alloy front panel
    • 12th Gen Intel® Whiskey Lake Core™ i3 / i5 / i7 Processor
    • 2 x DDR5 SDRAM, max.64GB, 2 x M.2 2280 NVMe or SATA SSD
    • 2 x Intel® 226-V 2.5GbE,1 x Intel® 219 1GbE Ethernet, WoL and PXE
    • 2 x RS232/422/485, RS485 support automatic flow control
    • Supports TPM2.0 security encryption and Intel vPro® Essentials
    • Supports embedded / VESA 100mm x 100mm mounting holes
    • 9V to 36V DC Wide Range Power Input,Supporting OVP / OCP / RPP
    CERoHSFCTPMIP66
    Visit:1561
    Description Specifications Dimension drawing Order Info Driver download

    System

    CPU

    12th Generation Intel® Core™ i3-1215U 1.2GHz

    12th Generation Intel® Core™ i5-1235U 1.3GHz

    12th Generation Intel® Core™ i7-1255U 1.7GHz

    TDP

    15W

    15W

    15W

    L3 Cache

    10MB

    12MB

    12MB

    Graphics

    Intel® UHD Graphics

    Intel® Iris® Xe Graphics

    Intel® Iris® Xe Graphics

    System Chipset

    Integrated With Intel® SoC

    Memory

    2 x DDR5 4800MHz 8GB, Up to 64GB

    Harddisk

    2 x M.2 120G SSD ( 250G / 500G / 2TB SSD)

    Network

    2 x Intel® I226, 2.5GbE / 1 x Intel® I219, 1GbE

    Audio

    Realtek ALC897 Audio controller

    TPM

    TPM 2.0

    Watchdog Timer

    255 Timer Levels, Set up by Software

    Operation System

    Windows 10 / 11, Linux, Ubuntu

    I/O

    VIDEO

    1 x H-DMI

    Ethernet

    3 x RJ45

    USB

    4 x USB 3.2 / 1 x Type-C x 1 ( USB 3.0 Gen 2, DP 1.4 )

    COM

    2 x RS-232 / 422 / 485 ( Adjustable through BIOS )

    Audio

    1x Audio_out & Mic_in

    Wireless Network

    Optional ( WiFi / Bluetooth / 4G / 5G )

    Expansion

    M.2

    1*M.2 ( Key-E, 2230, PCIe+USB, Wifi+BT )

    1*M.2 ( Key-B, 3042/3052, PCIe/ USB 3.0+USB2.0, 4G/5G )

    2*M.2 ( Key-M, 2280, NVMe/ SATA, SSD )

    SIM Socket

    1x SIM Socket

    Display

    LCD Size

    17" ( 5:4 )

    Resolution

    1280 x 1024

    Brightness (cd/m²)

    400 cd/m2

    Contrast Ratio

    1000:1

    Backlight MTBF

    50,000 hrs ( LED Backlight )

    Viewing Angle

    80 / 80 / 70 / 70 (CR≥10) ( L / R / U / D )

    Touch screen

    Touch Type

    Projected Capacitive Multi-touch

    Surface Hardness

    ≥7H

    Power

    Power Adapter

    1 x Optional AC/DC 12V/5A , 60W

    Power Mode

    Support AT, ATX Mode

    Power Input

    9~36VDC,2-Pin Terminal Block Connector with Power Input

    Power Protection

    OVP (Over Voltage Protection)  |  OCP (Over Current Protection)  |  RPP(Reverse Polarity  Protection)

    Power Consumption

    ≦45W

    Physical

    Material

    Aluminum alloy panel, anodized treatment

    Mounting

    Stand / Wall / VESA / Panel

    Dimension (W x H x D)

    395 x 327 x 65 mm

    Cut-out Size

    381 x 313 mm

    Packing Size

    500 x 180 x 450 mm

    Weight (Net)

    5.2 KG

    Environment

    Operating Temperature

    -20~70°C  ( -4~158°F )

    Storage Temperature

    -30~80°C (-22~176°F)

    Relative Humidity

    5%~95%@40°C, non-condensing

    Vibration Protection

    1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

    IP Level

    Front Panel IP66

    EMC

    CE, FCC,UL,KC ,Class A,ROHS ,IEC, EN 62368-1

    ORDERING INFORMATION

    AVAILABLE MODELS

    DESCRIPTION

    PPC-3017SAC-12th

    17" SXGA LCD / Resolution 1280 x 1024 / PCAP Touch / 12th Generation Intel® Core™ i3-1215U 1.2GHz / 1 x H-DMI / 3 x LAN / 4 x USB3.2 / 1 x Type-C / 2 x COM / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP)

    PPC-5017SAC-12th

    17" SXGA LCD / Resolution 1280 x 1024 / PCAP Touch / 12th Generation Intel® Core™ i5-1235U 1.3GHz / 1 x H-DMI / 3 x LAN / 4 x USB3.2 / 1 x Type-C / 2 x COM / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP)

    PPC-7017SAC-12th

    17" SXGA LCD / Resolution 1280 x 1024 / PCAP Touch / 12th Generation Intel® Core™ i7-1255U 1.7GHz / 1 x H-DMI / 3 x LAN / 4 x USB3.2 / 1 x Type-C / 2 x COM / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP)



    CONFIGURATION

    DESCRIPTION

    Memory

    RAM2 x DDR5 4800MHz 8GB, Up to 64GB

    Harddisk

    2 x M.2 120G SSD ( 250G / 500G / 2TB SSD)

    WiFi

    Wi-Fi Bluetooth Combo Module, with antenna

    4G/5G

    Full Netcom 4G/5G/LTE module, with antenna



    PACKING LIST

    1 x Standard product

    1 x CD-ROM

    1 x 60W PSU (Power Supply)

    1 x Power cable & plug

    8 x Panel mount metal clips
